Introducing New Humminbird® CHIRP Radar

New Humminbird® compact solid state radar module offers boaters CHIRP pulse compression technology for increased target detection and detail at long and short ranges


Humminbird® is pleased to announce the introduction of a new compact solid state radar module, complete with CHIRP pulse compression technology for outstanding radar imaging at short and long ranges.


“Humminbird® is excited to bring anglers and boaters the next generation of radar technology,” says Humminbird Brand Manager, Ray Schaffart. “Our new CHIRP Radar offers exceptional target separation technology to display approaching weather, boats, rocks, buoys and landmarks with impressive resolution. CHIRP pulse compression offers better target detection and detail at short or long ranges.”


CHIRP Pulse Compression uses frequency modulated radar pulses for increased target separation and detection, identifying targets with improved resolution over traditional magnetron radars, and optimized interference rejection. Boaters will discover that Humminbird® CHIRP Radar also installs easily and boots quickly for immediate use.


Schaffart continues: “Our new CHIRP Radar is also a huge improvement over past Humminbird® models in terms of compact footprint, negligible weight, greatly reduced power consumption and reduced emissions, as well as battery life. The product is a great navigational and safety addition when paired with compatible Humminbird® equipment.”




Antenna Dimension 21”” Enclosed Dome (18” array)
Antenna Type Patch Array
Peak Power Output 20W
Transmit Frequency 9354 to 9446 MHz
Beamwidth (nominal) 4.9° Horizontal, 20° Vertical
Input Voltage 12 or 24 Vdc (Min: 10.8V; Max 31.2V)
Networking Ethernet
Power Consumption Transmit mode 17W; standby mode 7W
Max. Range Scale 1/16 to 24 nautical miles
Duplexer Circulator
Pulse Widths (3 dB) 40 ns to 14.7 µs
CHIRP lengths 400 ns to 20 µs
CHIRP Bandwidth Up to 32 MHz
IF Bandwidth 26 MHz
Noise Less than 4 dB
Polarization Horizontal
Waterproofing IPX6
Weight 5.6 kg (12.3 lb)



Johnson Outdoors Marine Electronics, Inc. consists of the Humminbird®, LakeMaster®, Minn Kota® and Cannon® brands. Humminbird® is a leading innovator and manufacturer of fishfinders, fishfinder/GPS combo units, ice flashers and digital depth gauges. LakeMaster® is the premier brand of high-definition electronic fishing charts. Minn Kota® is the world’s leading manufacturer of electric trolling motors, as well as offers a complete line of shallow water anchors, battery chargers and marine accessories. Cannon® is the leader in controlled-depth fishing and includes a full line of downrigger products and accessories.

For sales information:
Motocraft SA
Alimou Ave. 48
17455 Alimos
phone 210 9888288
